VWP-MV-LE80E
4K 30 Seamless HDMI Multiviewer VIdeo wall Controller 40SLT
Key Features
- Pure FPGA hardware architecture, zero crashes/virus risks
- Seamless switching without black screen intervals
- Supports multi-window display with roaming and PiP
- Store and recall up to 64 preset scenes
- Static base map output without external devices
- Subtitle and logo overlay with custom style options
- 4K×2K ultra-high resolution support
- Independent multi-screen grouping with custom resolutions
- Multiple control options: touchscreen, LAN, RS-232, central, app
- Authority management with multi-user access levels
- Dual redundant power supply for stable operation
Description
Overview
The Macsys VWP-MV-LE80E is an advanced 4K 30Hz seamless HDMI multiviewer and video wall controller built on a reliable FPGA pure hardware architecture. Unlike systems that rely on software-based operating platforms, this controller ensures stability with zero risks of crashes, virus intrusions, or compatibility issues, making it a dependable choice for mission-critical operations.
Engineered to deliver seamless switching, multiview processing, and large-scale video wall control, it allows multiple input signals to be displayed simultaneously across different screens or within independent screen groups without delay or interruption. Its powerful video processing supports flexible operations such as multi-window display, picture-in-picture, roaming, stretching, and rotation, while allowing up to 64 visual scene presets to be stored and recalled with ease.
The device incorporates high-resolution 4K×2K output, static base map capability without external sources, customizable subtitles, and logo overlay functions, ensuring an engaging and professional display experience. Output adjustments, user-friendly operation, and versatile control options (touchscreen, Ethernet, RS-232, central control, iPad, and Android) make it adaptable across industries.
With multi-user authority management, redundant power options, and flexible customization of resolutions per output group, the VWP-MV-LE80E is a complete and secure solution. It is ideal for deployment in education, government command and monitoring centers, exhibitions, information release, military command systems, administrative management, and professional AV applications requiring reliable and high-performance video wall control.
Technical specifications
| Feature | Details |
| Architecture | FPGA pure hardware, no operating system |
| Input/Output Scale | 19–22 Input / 15–18 Output |
| Supported Resolution | Maximum 4K × 2K @ 30 Hz, downward compatible |
| Image Processing | Seamless switching, no black field intervals during signal changes |
| Multi-Window Functions | Window opening, superimposing, stretching, zooming, PiP, roaming |
| Scene Management | Store up to 64 scenes; supports scene rotation |
| Subtitle Function | Custom fonts, colors, background color selection, scrolling speed, adjustable position, multi-greeting storage |
| Logo/Overlay Support | Custom labeling and station logo superimposition, adjustable font color and position |
| Base Map Function | Static base map output without need for PC, SD card, or external storage; supports point-to-point output |
| Output Adjustments | Brightness, contrast, and saturation per output interface |
| Multi-Screen Grouping | Independent multi-group splicing control, customization of resolution per group, independent group operation |
| Control Options | Front panel touchscreen, LAN, RS-232, Central control, iPad, Android, PC |
| Authority Management | Multi-user access with configurable permissions by management software |
| Storage Environment | Free from corrosive gases, solvents, dust, and strong magnetic fields |
| Power Supply | 4 redundant power supply (hot-swappable) |
| Main Power Input | 100–240 VAC, 50–60Hz |
| Operating Temperature | 0–40 °C |
| Storage Temperature | –10–60 °C |
| Storage Environment | Free from corrosive and solvent gases, no dust, no strong magnetic field interference |
| Size | 11U Rackmount |
| Certifications | CE, RoHS compliance |
Front Panel
Rear Panel
Connection Diagram
