ECON-16MS
UHD hybrid modular matrix switcher 16×16
Key Features
- UHD 4K30 seamless matrix switching for professional AV applications.
- Customizable modular I/O cards: HDMI/DVI/VGA/SDI/HDBaseT/CVBS/Fiber.
- Flexible local and network control: panel keys, RS‑232, IR, TCP/IP.
- Scene presets and EDID learning for easy room reconfiguration and display compatibility.
- Real-time system status via LCD and indicators for mission-critical environments.
Description
Overview
The ECON series delivers high-resolution UHD 4K switching with customizable HDMI, DVI, VGA, SDI, HDBaseT, CVBS, and fiber inputs/outputs. Seamless switching, EDID learning, scene presets, and flexible local/network control make it perfect for professional AV installations, control rooms, and large conference environments.
Technical specifications
| Feature | Details |
| Matrix capacity | 16×16 switching, AV crosspoints |
| Input card slot | 4 slots |
| Output card slot | 4 slots |
| RS‑232 ports | 2×DB9 |
| TCP/IP control (RJ45) | Present |
| Voltage selector | 110/230 V selector |
| AC power inlet | 100–240 VAC, Power changeover switch for selecting 110V or 240V input. |
| Earth/ground terminal | Yes |
| Front keypad (channels) | 0–9 keys (multi‑digit for >9) |
| IR receiver | Built‑in IR |
| LCD status display | Green backlight LCD |
| Supported resolution | UHD 4K (3840×2160p) @ 30Hz |
| Card types (I/O) | HDMI, DVI, VGA, 3G‑SDI, HDBaseT, CVBS, Fiber (modular, mix‑and‑match) |
| Seamless switching/splicing | Seamless switching with power-off memory and A/V sync |
| EDID learning | Learning for display compatibility |
| OSD Functions | Subtitle overlay support |
| Subtitle overlay | Supported |
| Scene Presets Group | Supports saving and recalling 10 scene groups |
| Control methods | Front-panel keys, 2xRS‑232, IR, TCP/IP |
| Certifications | CE, RoHS compliance |
Front Panel
Rear Panel
Connection Diagram
